Metal FX® Delta 15" UTV Beadlock Wheel: 4x136/4x156 | Gunmetal Contrast Cut

Metal FX Delta Beadlock UTV Wheel

Gunmetal Base. Bright Accents.

Gunmetal gives this Delta a darker metallic tone than black, and the contrast-cut accents add bright aluminum along the concave face. The result reads as gray-and-silver rather than black-and-silver.

Sizes stay the same across the 4-lug Delta: 15x7 (+25mm, 4.5+2.5) and 15x10 (+0mm, 5+5), with 4x137 and 4x156 drillings. Center caps for this finish use Metal FX part 10312. Metal FX lists both widths with the same 1,000 lb rating as the black Deltas.

Each Delta wheel in Gunmetal Contrast Cut is A356-T6 cast aluminum with a 6061-T6 forged aluminum beadlock ring. Metal FX lists the weight at 17 lbs for the 15x7 and 19 lbs for the 15x10. Center caps for this finish are part 10312. The matching replacement beadlock ring is part 10203.

Features and Benefits

• Gunmetal Contrast Cut: Gray-and-silver rather than black-and-silver, the outlier among 4-lug Delta finishes.
• Concave Face: Metal FX's Delta casting puts the spokes in a dished profile for visual depth.

Bolt Pattern Application Guide

Always confirm your machine's bolt pattern, hub and brake clearance before ordering.

• 4x136/4x137 (4/137) Bolt Pattern (110.2mm center bore; 15x7 +25mm, 15x10 +0mm): Metal FX lists this pattern for Can-Am and Honda.
• 4x156 (4/156) Bolt Pattern (132mm center bore; 15x7 +25mm, 15x10 +0mm): Metal FX lists this pattern for Kawasaki, Polaris, Yamaha (2019+) and Speed UTV.

Delta Gunmetal Contrast Cut Specifications

PLEASE NOTE: Single wheel purchase only, tire and extra vehicle accessories NOT included! Double-check your machine's bolt pattern, offset, and fitment clearances before ordering to ensure absolute accuracy.

Important Fitment & Legal Notes

• Off-Road Use Only: Metal FX builds its beadlock wheels for dedicated off-road use. Beadlock wheels are not legal on public roads in many states and provinces, so check your local laws before you ride.
• Beadlock Maintenance: Torque the beadlock ring bolts to Metal FX's specification when the tire is mounted, then recheck them after the first few rides and after any hard hit. Mounting a beadlock takes longer than a standard wheel, so use a shop experienced with beadlocks if you aren't set up for it.
• Lug Nuts Required: These wheels require aftermarket lug nuts (sold separately).
• Remove Mud Scrapers: Before installing, remove your machine's factory mud scrapers to avoid damaging the wheels. Metal FX publishes removal instructions.
• Construction: A356-T6 cast aluminum wheel with a 6061-T6 forged aluminum beadlock ring.
• Warranty: Covered by Metal FX's One-Year Limited Structural manufacturer warranty: one year against material defects and 30 days against workmanship defects from the date of receipt. Beadlock rings are not covered, and bent or cosmetically damaged wheels are excluded.

UTV Application Warning: Customers and/or users are responsible for ensuring that this product is compatible with their machines as currently configured. Professional installation of beadlock hardware is highly recommended, and routine safety inspections on the beadlock ring torque specs are required before trail usage.
