Metal FX® Mayhem R 15" UTV Beadlock Wheel: 5x114.3 | Gloss Silver Machined

SKU: 98872

$489.00 – $499.00

  • Wheel Color: Gloss Silver Machined
  • Size: 15x8 | 15x10
  • Bolt Pattern: 5x114.3
  • Fits: Polaris 5-Lug, Segway Super Villain & Kawasaki H2
  • Offset: +0mm
  • Wheel Type: Beadlock

Also available in Gloss Black | Gloss Black Contrast Cut

Other bolt patterns for this wheel: 4x136/4x156 | 6x139.7

Regular price $499.00
Free Shipping All 48 contiguous states
No Sales Tax Except Indiana & Michigan orders
ORDERED
Today
EXPECTED ARRIVAL
Calculating...

Metal FX Offroad Logo

Metal FX Mayhem R Beadlock UTV Wheel

5-Lug Attitude. A Bright New Edge.

Bring a brighter finish to your 5-lug off-road build with the Mayhem R Beadlock by Metal FX. Built for the days when the trail calls for more than just a good-looking wheel, the Mayhem R pairs a clean, metallic aesthetic with heavy-duty, functional beadlock performance. Whether you are picking a technical line through the rocks or heading out across open terrain, this wheel puts purposeful hardware at the center of your setup.

Platform-specific for 5-lug hubs, the Mayhem R utilizes a 5x114.3 (5x4.5) bolt pattern. Available in both 15x8 and 15x10 sizes at a +0mm offset, you can dial in the exact width that suits your machine's stance while maintaining the unmistakable Metal FX character across your entire rig.

Each Mayhem R wheel in Gloss Silver Machined is A356-T6 cast aluminum with a 6061-T6 forged aluminum beadlock ring. Metal FX does not currently publish a weight for this finish. Center caps for this finish are part 10349. The matching replacement beadlock ring is part 10254.

Features and Benefits

  • Gloss Silver Machined Finish: Delivers a crisp, bright metallic character that serves as a fresh alternative to traditional blacked-out setups, giving your build a premium finishing touch without losing the aggressive Mayhem attitude.
  • True Beadlock Design: A fully functional beadlock ring mechanically clamps the tire's outer bead to the wheel, keeping it firmly seated when running lower tire pressures for maximum traction.
  • Premium Construction: Manufactured using a lightweight yet incredibly strong A356-T6 cast aluminum wheel center, paired with a rugged 6061-T6 forged aluminum beadlock ring.
  • Wheel Offsets: Offered in 15x8 (+0mm / 4+4) and 15x10 (+0mm / 5+5) configurations.

Bolt Pattern Application Guide

Always confirm your machine's bolt pattern, hub and brake clearance before ordering.

  • 5x114.3 (5x4.5) Bolt Pattern (66.1mm center bore; 15x8 +0mm, 15x10 +0mm): Metal FX lists this pattern for Polaris 5-lug machines and Segway Super Villain.

Mayhem R Gloss Silver Machined Specifications

Spec 15x8 Wheel 15x10 Wheel
Part Number 98862 98872
Finish Gloss Silver Machined Gloss Silver Machined
Bolt Pattern 5x114.3 5x114.3
Center Bore 66.1mm 66.1mm
Offset +0mm +0mm
Backspacing 4+4 (4.4") 5+5 (5.4")
Weight Not listed Not listed
Load Rating 1,260 lbs 1,260 lbs
Lip Size 2.05" 3.06"
Center Cap 10349 10349
Center Cap Hardware 10644 10644
Beadlock Ring 10254 10254
Beadlock Hardware 10608 10608
Construction Cast wheel, forged ring Cast wheel, forged ring

PLEASE NOTE: Single wheel purchase only, tire and extra vehicle accessories NOT included! Double-check your machine's bolt pattern, offset, and fitment clearances before ordering to ensure absolute accuracy.

Important Fitment & Legal Notes

  • Off-Road Use Only: Metal FX builds its beadlock wheels for dedicated off-road use. Beadlock wheels are not legal on public roads in many states and provinces, so check your local laws before you ride.
  • Beadlock Maintenance: Torque the beadlock ring bolts to Metal FX's specification when the tire is mounted, then recheck them after the first few rides and after any hard hit. Mounting a beadlock takes longer than a standard wheel, so use a shop experienced with beadlocks if you aren't set up for it.
  • Lug Nuts Required: These wheels require aftermarket lug nuts (sold separately).
  • Remove Mud Scrapers: Before installing, remove your machine's factory mud scrapers to avoid damaging the wheels. Metal FX publishes removal instructions.
  • Construction: A356-T6 cast aluminum wheel with a 6061-T6 forged aluminum beadlock ring.
  • Warranty: Covered by Metal FX's One-Year Limited Structural manufacturer warranty: one year against material defects and 30 days against workmanship defects from the date of receipt. Beadlock rings are not covered, and bent or cosmetically damaged wheels are excluded.

UTV Application Warning: Customers and/or users are responsible for ensuring that this product is compatible with their machines as currently configured. Professional installation of beadlock hardware is highly recommended, and routine safety inspections on the beadlock ring torque specs are required before trail usage.
